| Tempat asal: | Cina |
|---|---|
| Nama merek: | YIZGEAR |
| Nomor model: | HB22083001 |
| Kuantitas min Order: | 1 set |
| Harga: | $1000/ Set |
| Kemasan rincian: | peti kayu lapis |
| Waktu pengiriman: | 75 hari |
| Syarat-syarat pembayaran: | L/C,T/T |
| Menyediakan kemampuan: | 50 Set/Bulan |
| Gear Profile: | Herringbone Gear | Hub Diameter: | 90 |
|---|---|---|---|
| Hardness: | 260 HB | Helical angle: | 25° |
| Pressure angle: | 20° | Teeth Width: | 55 |
| Menyoroti: | Baja Pinion Herringbone Gear Tempa,SAE 4340 Steel Pinion Gear,SAE 4340 Pinion Herringbone Gear |
||
| Profil Gear | Peralatan Herringbone |
| Diameter Hub | 90 |
| Kekerasan | 260 HB |
| Sudut spiral | 25° |
| Sudut tekanan | 20° |
| Lebar gigi | 55 |
| Disesuaikan | √ |
| Jenis Profil Gir | Tulang ikan Herring |
| Pabrik gigi gigi | Penggilingan Gir |
| Penggilingan Gigi Gear | Tidak ada |
| Modul (M) | 7 |
| Jumlah Gigi (Z) | 17 |
| Sudut Tekanan (α) | 20° |
| Sudut Heliks (β) | Adat |
| Tingkat Keakuratan Gigi | Kelas ISO 8-9 |
| Pengolahan Panas | Memadamkan & Mengeraskan |
| CHINA/GB | ISO | GOST | ASTM | JIS | DIN |
|---|---|---|---|---|---|
| 45 | C45E4 | 45 | 1045 | S45C | CK45 |
| 40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
| 20CrMo | 18CrMo4 | 20XM | 4118 | SCM22 | 25CrMo4 |
| 42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
| 20CrMnTi | 18XGT | SMK22 | |||
| 20Cr2Ni4 | 20X2H4A | ||||
| 20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
| 40CrNiMoA | 40XH2MA/40XHMA | 4340 | SNCM 439 | 40NiCrMo6/36NiCrMo4 | |
| 20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 |
