| Tempat asal: | Cina |
|---|---|
| Nama merek: | YIZGEAR |
| Nomor model: | HB22082601 |
| Kuantitas min Order: | 1 buah |
| Harga: | $500/ Piece |
| Kemasan rincian: | peti kayu lapis |
| Waktu pengiriman: | 72 Hari |
| Syarat-syarat pembayaran: | L/C,T/T |
| Menyediakan kemampuan: | 300 PCS/Bulan |
| Jenis Profil: | gigi herringbone | Bahan: | SAE 4340 |
|---|---|---|---|
| Kekerasan: | 230-260hb | Lebar: | 110mm |
| Modul: | Modul 5-25 | Pemrosesan pembuatan: | Penggilingan Gigi |
| Menyoroti: | SAE 4340 Gigi Herringbone Heliks Ganda,SAE 4340 Gigi Herringbone Heliks,260HB Gigi Heliks Ganda |
||
| Atribut | Nilai |
|---|---|
| Jenis Profil | Peralatan Herringbone |
| Bahan | SAE 4340 |
| Kekerasan | 230-260HB |
| Lebar | 110 mm |
| Modul | Modul 5-25 |
| Pabrik Pengolahan | Penggilingan Gir |
| Produk | Set Gear Herringbone |
|---|---|
| Disesuaikan | √ |
| Jenis Profil Gir | Peralatan silinder |
| Pabrik gigi gigi | Penggilingan Gir |
| Penggilingan Gigi Gear | √ |
| Modul (M) | Modul 5-25 |
| Jumlah Gigi (Z) | Adat |
| Sudut Tekanan (α) | 20° |
| Sudut Heliks (β) | Adat |
| Tingkat Keakuratan Gigi | Kelas ISO 8-9 |
| Pengolahan Panas | Memadamkan & Mengeraskan |
| Kekerasan permukaan | 230-260 HB |
| CHINA/GB | ISO | GOST | ASTM | JIS | DIN |
|---|---|---|---|---|---|
| 45 | C45E4 | 45 | 1045 | S45C | CK45 |
| 40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
| 20CrMo | 18CrMo4 | 20XM | 4118 | SCM22 | 25CrMo4 |
| 42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
| 20CrMnTi | 18XGT | SMK22 | |||
| 20Cr2Ni4 | 20X2H4A | ||||
| 20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
| 40CrNiMoA | 40XH2MA/40XHMA | 4340 | SNCM 439 | 40NiCrMo6/36NiCrMo4 | |
| 20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 |
